MSG Magnetic Rack
MSG Magnetic Rack series utilizes high-performance permanent magnets for the gentle, tube-based separation and purification of magnetically labeled targets such as nucleic acids, proteins, and cells. The series offers four specifications, covering working volumes from 5μL up to 50mL.
Features of MSG Magnetic Rack
- Uniform & Stable Magnetic Field: Provides a consistent and stable magnetic field.
- Low Magnetic Bead Aggregation: Designed to minimize magnetic bead clumping.
- Ergonomics: Features intuitive hand-feel and positioning to reduce operator fatigue.
- High Recovery & Consistent Results: Ensures reliable intra- and inter-batch performance with less material loss and tighter Coefficients of Variation (CVs).
- Excellent Visibility & Sample Control: Visible bead aggregation zones allow for precise supernatant removal or retention, effectively reducing sample loss.
Description of MSG Magnetic Rack
The MSG series of magnetic racks is designed for versatile applications and a wide range of working volumes. They are compatible with common laboratory consumables, including 0.2mL PCR tubes/strips and plates, 1.5/2.0mL microcentrifuge tubes, 5/15/50mL conical tubes, and cell culture plates.
Technical Parameters
| Specification | Working Volume | Compatibility |
| MSG-96 | Micro-volume: 5μL−200μL | 0.2mL PCR tubes/strips/plates |
| MSG-2 | Small: 10μL−2mL | 1.5/2.0mL microcentrifuge tubes |
| MSG-15 | Medium: 1mL−15mL | 5/15mL conical tubes |
| MSG-50 | Large: 5mL−50mL | 50mL conical tubes, cell-culture plates |
Applications of MSG Magnetic Rack
- Nucleic acid separation and purification: DNA/RNA extraction, library construction cleaning, and purification after polymerase chain reaction.
- Protein purification: Magnetic bead affinity purification.
- Cell sorting: Enrichment and removal of cells labeled with magnetic beads.
Why Choose Our MSG Magnetic Rack?
- High Performance: high-performance permanent magnets to deliver a uniform and stable magnetic field and ensure low magnetic bead aggregation.
- Consistency: high recovery and consistent results with less material loss and tighter Coefficients of Variation (CVs).
- Ergonomics: ergonomic design and intuitive positioning help reduce operator fatigue.
- Compatibility: working volumes (5μL to 50mL) and common laboratory consumables.
